T366 Series

Affordable Vehicle GPS Tracker

2G/3G/4G network

Has three versions running on 2G, 3G and 4G
networks respectively.

Flexible configurable I/O

Offer outstanding configuration flexibility to cater to a wide variety of requirements.

IP67 water resistant

Specialized design provides a tough casing that stands up to the elements.

Driving behavior analysis

Detect driver behaviors, such as the driver fatigue, idling, harsh acceleration/braking, harsh cornering, collision, etc.

Application

Off-road Vehicle

Fire Engine

Beach Buggy

Yacht

Specifications

ItemSpecifications
Dimension80.5 mm x 60 mm x 23.5 mm
Weight100g
I/O power cable length50cm
Power SupplyDC 11~90 V/1.5A
Power ConsumptionCurrent in standby mode: 65 mA
Operating Temperature-35°C to 80°C (available for the device without a battery)
Operating Humidity5% to 95%
LED indicatorGreen indicator showing the 2G/3G/4G signal
Blue indicator showing the GPS signal
Button/Switch1 upgrade button (used to manually upgrade the firmware)
1 power button
Memory8 MB buffer
Sensor3-axis accelerometer (used to wake the device up by vibration and
detect towing alerts, harsh acceleration alerts, and harsh braking alerts)
Frequency BandT366:
GSM/GPRS: 850/900/1800/1900 MHz
T366G:
T366G-E: UMTS/HSDPA: 900/2100 MHz, GSM/GPRS: 900/1800 MHz
T366G-A: UMTS/HSDPA: 850/1900 MHz, GSM/GPRS: 850/900/1800/1900 MHz
T366G-T: UMTS/HSDPA: 850/2100 MHz, GSM: 850/900/1800/1900 MHz
T366L:
T366L-E: LTE FDD:B1/B3/B7/B8/B20/B28A, WCDMA: B1/B8, GSM/GPRS: B3/B8
T366L-A: LTE FDD:B2/B4/B12, WCDMA: B2/B4/B5
T366L-AU: LTE FDD:B1/B2/B3/B4/B5/B7/B8/B28, LTE TDD:B40,
WCDMA: B1/B2/B5/B8, GSM/GPRS: B2/B3/B5/B8
T366L-AUT: LTE FDD:B1/B3/B5/B7/B28, WCDMA: B1/B5
T366L-G: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28,
LTE TDD: B38/B39/B40/B41, WCDMA: B1/B2/B4/B5/B6/B8/B19,
GSM/GPRS: B2/B3/B5/B8
GPS Sensitivity-165 dB
Positioning accuracy2.5m

Accessories

  • T366 Series Tracker
  • L wrench
  • Hexagon screw
  • 400 mAh battery
  • CD download card

Optional Accessories

  • A52 digital temperature sensor
  • A53 fuel level sensor
  • A57 speaker
  • A58 microphone
  • A64 remote control receiver
  • A67 remote control
  • Relay (12 V/24 V)
  • External GPS antenna
  • Ultrasonic fuel level sensor
  • RFID
  • Buzzer
  • USB cable
  • iButton reader
  • LED display
