T622 Series

Advanced Vehicle GPS Tracker

3G/4G Network

Has two versions running on WCDMA (Iridium optional) and LTE Cat M1/Cat NB1 networks respectively.

Garmin Fleet Tracking

Streamline dispatching with Garmin integration to further improve business efficiencies.

Mobileye Fleet Safety

Compatible with Mobileye collision avoidance system to keep your drivers and assets safe.

Multi-functional

Support CAN bus, camera, LED display, fuel/temperature sensor, iButton.

Application

Truck

Garbage Truck

Armor Cash Carrier

Ambulance

Specifications

ItemSpecifications
Dimension105 mm x 65 mm x 26 mm
Weight190g
Power supplyT622G & T622E: DC 11–36 V/1.5 A
T622G_F9: DC 11.4–36 V/1.5 A
Backup battery400 mAh/3.7V
Operating temperatureT622G & T622E: -20°C to 55°C
T622G_F9: -10°C to 55°C
Operating humidity5% to 95%
Working hour53 hours in power-saving mode
5.5 hours in normal mode
Sensor3-axis accelerometer
Memory8 MB buffer
Frequency bandT622G:
UMTS/HSDPA: 800/850/900/1900/2100 MHz
GSM/GPRS: 850/900/1800/1900 MHz
T622G_F9:
UMTS/HSDPA: 800/850/900/1900/2100 MHz
GSM/GPRS: 850/900/1800/1900 MHz
Iridium satellite:
Frequency band: 1616–1626.5 MHz, Duplex mode: TDD,
Multiplexing mode: TDMA/FDMA
T622E:
Cat M1 & NB1:
LTE FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B26/B28
LTE TDD: B39(for Cat M1 only)
EGPRS: 850/900/1800/1900
Positioning accuracy.5m

Accessories

  • T622 Series tracker
  • GPS antenna
  • 3G/4G antenna
  • Iridium antenna(T622G_F9)
  • I/O cable
  • USB cable
  • CD download card

Optional Accessories

  • Camera
  • iButton
  • LLS sensor
  • LED display
  • A76 ultrasonic fuel level sensor
  • Garmin navigator
  • A53 fuel level sensor
  • A52 digital temperature sensor + A61 sensor box
